Code 4803, 4823
Bore: 4.19 in (106.5)
Pin Diameter: 1.375 in (35mm) - "Small Pin"
Piston marked: RE59277, RE505100, RE515372
Cylinder Kit Number RE507920
Connecting rod: R123959 Machined, R500000 Fractured
4045HT051, 4045TF120, 4045TF150, 4045TF151, 4045TF158, 4045TF270, 4045TF275, 4045TLV54, 4045TLV56, 4045TP066, 4045TRT50, 4045TT050, 4045TT056, 4045TT066, 4045TT081, 4045TT082, 4045TT088, 4045TT089, 4045TT090, 4045TT092, 4045TT093, 4045TT094, 4045TT096
Fits:
John Deere Agricultural Machine Models: 3410, 3410X, 4890, 4895, 5415, 5425, 5510, 5520, 5525, 5615, 5625, 5715, 5725, 6700, 5425N, 5510N, 5520N, 5525N, 5625N
Aksa: APD-AGJ60, APD-AT65, APD-EPAJ65, APD-ULJ65
Construction Models: 230 LCR, 310E, 310G, 310SE, 310SG, 315SE, 315SG, 344H, 410E, 410G, 410J, 450H, 550H, 650H
Skid Steer Models: 280, 280 Series II
SDMO Generator: J60U, J66K, J70U, J77K
Inframe Kit Includes:
(4) Cylinder Kits (Piston, Liner, Piston Rings, Piston Pin, Pin Retainers)
(4) Rod Bearing Pairs
(1) Main Bearing Set
(1) Head Gasket Set
(1) Oil Pan Gasket
(8) Rod Bolts
Overhaul Kit Includes:
(4) Cylinder Kits (Piston, Liner, Piston Rings, Piston Pin, Pin Retainers)
(4) Rod Bearing Pairs
(1) Main Bearing Set
(1) Overhaul Gasket Set
(8) Rod Bolts
(1) Rear Crankshaft Seal
(1) Front Crankshaft Seal
(4) Piston Pin Bushings
(6) Balance Shaft Bushings*
*If you are replacing the balance shaft bearings in this kit, you will need to swedge these bushing once installed. This requires a special tool (John Deere Service Guard # JD255-1)
Please note: Cylinder head bolts must be replaced when rebuilding this engine. They are sold separately (see related products below).
